Victron Skylla - 24/100 TG Charger - 230V

The Skylla 24/100 TG Charger is the perfect solution for marine enthusiasts seeking reliable and efficient battery charging on board. Designed to meet the demanding needs of marine and boating environments, this charger ensures your batteries are always ready for your next adventure.

Product Overview

The Skylla 24/100 TG Charger offers one fully rated output and an additional 4 Amp output, providing versatile charging options for various battery systems. With precise charge voltage adjustment, it caters to both sealed and unsealed batteries, ensuring optimal performance and longevity.

Key Features

• Universal Compatibility: Ideal for any type of battery, sealed or unsealed. Perfectly adjusted charge voltage prevents overvoltage, excessive gassing, and venting, thus extending battery life.
• Dual Supply Capability: Compatible with both AC and DC power sources, allowing for flexible installation and usage in different marine setups.
• Advanced Microprocessor Control: The built-in microprocessor manages charging in three precise steps, ensuring efficient and safe battery charging.
• Reliable Power Supply: Stabilized output voltage makes the TG Charger suitable as a standalone power supply when batteries or large buffer capacitors are unavailable.
• Temperature Compensation: Equipped with an external battery temperature sensor, the charger automatically adjusts the charge voltage based on battery temperature for optimal charging conditions.
• Voltage Loss Compensation: Features a voltage sensor that compensates for voltage drop due to cable resistance, ensuring your battery receives the correct charge voltage at all times.

Technical Specifications

Specification	Details
Input Voltage	230V AC
Input Voltage Range	185 to 264V AC
DC Input Voltage Range	180 to 400V DC
Battery Capacity	500 to 1000 Ah
Frequency	45 to 65 Hz
Battery Connection	M8 studs
230V AC Connection	Screw clamp (AWG 6)
Dimensions (H x W x D)	14.4" x 9.9" x 10.1" (36.5 x 25 x 25.7 cm)
Weight	22 Lbs (10 kg)

What's Included

• Skylla 24/100 TG Charger
• Mounting Brackets
• Temperature Sensor with 4.9' (1.5 M) Wire
• Instruction Manual

*Sold individually*

Additional Resources

• Quick Guide (pdf)
• Owner's Manual (pdf)
• Brochure (pdf)

Support & Service: Please contact your dealer for any returns, repairs, or support issues related to the Skylla 24/100 TG Charger. Our dedicated team is here to ensure your marine adventures are always powered by reliable and efficient battery solutions.
