Victron BMV-710H Smart High Voltage Battery Monitor (60-385VDC)

Optimize your marine adventures with the BMV-710H Smart High Voltage Battery Monitor. Designed specifically for boating enthusiasts, this advanced monitor ensures you have real-time insights into your battery's performance, helping you make informed decisions while on the water.

Advanced Battery Monitoring for Marine Applications

The BMV-710H Smart integrates seamlessly into your marine setup, offering wireless connectivity through Bluetooth. Easily connect to your smartphone or tablet via the VictronConnect App to access a comprehensive overview of your battery's health, including state of charge, time remaining, and detailed historical data.

Key Features

• Real-Time Battery Insights: Monitor voltage, current, power consumption, ampere-hours consumed, and state of charge at a glance.
• Time-to-Go Indicator: Know exactly how much time you have left based on your current discharge rate.
• Customizable Alarms: Set visual and audible alerts to notify you of critical battery levels.
• Smart Relay Control: Automatically manage non-critical loads or initiate generator start based on battery status.
• High Current Capacity: Equipped with a 500A quick connect shunt, expandable up to 10,000 amps for diverse marine setups.
• Reliable Communication: VE.Direct port ensures seamless integration with other Victron products.
• Energy Efficiency: Low current consumption helps preserve battery life when the system is idle.

Comprehensive Specifications

Specification	Details
Supply Voltage Range	60 – 385 VDC
Current Draw (Back Light Off)	< 4mA
Battery Capacity	1 - 9999 Ah
Operating Temperature Range	-40 to +50°C (-40 to 122°F)
VE.Direct Communication Port	Yes
Relay Specifications	60V / 1A normally open (inversion possible)

Installation Made Simple

Installing the BMV-710H Smart is straightforward, designed to fit seamlessly into your marine environment:

• Quick Connect PCB: All electrical connections attach to the integrated PCB on the current shunt.
• Standard Cabling: Connect the shunt to the monitor using the included 10m RJ12 telephone cable.
• Mounting Accessories: Comes with a round head unit, a square bezel overlay for a customizable look, a securing screw ring, and all necessary mounting screws.

Smartphone Integration

Easily program and monitor your battery system using your smartphone:

• App Support: Access detailed settings and real-time data through the VictronConnect App available on Apple and Android devices.
• Bluetooth Connectivity: Utilize the built-in Bluetooth Smart dongle for a seamless wireless experience.

Technical Accuracy and Performance

The BMV-710H Smart ensures precise monitoring with high-resolution measurements:

Parameter	Resolution & Accuracy
Current	± 0.01A
Voltage	± 0.01V
Amp Hours	± 0.1 Ah
State of Charge	± 0.1%
Time to Go	± 1 min
Current Measurement Accuracy	± 0.4%
Voltage Measurement Accuracy	± 0.3%

Durable and Reliable Construction

Built to withstand the demanding marine environment:

• Protection Rating: IP55 ensures resistance against dust and water jets, suitable for indoor and sheltered outdoor use.
• Compact Design: Flush mount installation with dimensions of 63mm diameter for the face and 69x69mm for the bezel.
• Robust Shunt Enclosure: The high-voltage shunt is securely housed to ensure safety and reliability.

Compliance and Standards

Standard	Compliance
Safety	EN 60335-1
Emission / Immunity	EN 55014-1 / EN 55014-2
Automotive	ECE R10-4 / EN 50498

Included Accessories

• 500A / 50mV Shunt: Essential for accurate current measurement.
• Cabling: Includes a 10-meter 6-core UTP cable with RJ12 connectors and a battery cable with a 1Amp slow-blow fuse for secure connections.
• Optional Temperature Sensor: Enhance monitoring with temperature data (Model: ASS000100000).

Please contact your dealer for any returns, repairs, or support issues related to this product.

Additional Resources

Quick Guide (PDF)

Brochure (PDF)
