Newmar PT-80 Battery Charger

Enhance your marine power system with the PT-80 Battery Charger from Newmar’s Phase Three Series. Designed specifically for 12-volt marine applications, this charger delivers intelligent three-stage charging to ensure rapid battery recovery, optimal conditioning, and extended battery lifespan. Whether you’re outfitting a workboat, military vessel, commercial ship, or recreational craft, the PT-80 provides reliable and efficient power management to keep your operations running smoothly.

Advanced Charging Technology

The PT-80 Battery Charger utilizes smart charging technology that interacts seamlessly with your batteries. It employs a three-stage charging process—bulk, absorption, and float—to maximize performance and extend battery life. This intelligent approach ensures your batteries are always maintained at their optimal state, ready to deliver peak performance when you need it most.

Customizable Charging Settings

Adapt the PT-80 to your specific battery type with ease. A convenient selector switch allows you to choose between gel-cell, flooded lead-acid, or AGM battery types, ensuring the charger provides the appropriate voltage for each. Additionally, an optional temperature compensation sensor fine-tunes the output based on ambient temperature changes, maintaining ideal charging conditions regardless of the environment.

Durable Marine-Grade Construction

Built to withstand the harsh marine environment, the PT-80 is housed in a rugged stainless steel case with a durable white powder coat finish. The internal circuitry is polyurethane coated to offer maximum corrosion resistance, ensuring long-term reliability and performance even in the most demanding conditions.

Key Features

• 12-volt model ideal for marine applications
• Smart three-stage charging: bulk, absorption, and float
• Selector switch for Gel-Cell, Flooded Lead-acid, or AGM batteries
• Multiple isolated output banks with ammeter for total output current (Except PT-7)
• Optional temperature compensation sensor for optimal voltage adjustments (Except PT-7)
• Current limitations to prevent overloading and potential damage
• Clean, well-regulated output suitable for use as a power supply or direct load powering without a battery
• Rugged stainless steel case with white powder coat finish and marinized internal circuitry
• Comprehensive protection features: Current Limiting, Thermal Protection, Forced Air Cooling, Drip Shield
• ABS-type approval for battery charging and power supply applications

Technical Specifications

Specification	Details
Input Voltage (VAC)	90-264 VAC (50-60 Hz)
Input Amps @ Full Load	12 A @ 115 VAC, 7 A @ 230 VAC
Power Factor	0.95 @ 230V, 0.98 @ 115V
Max Output Amps	80 A
Output Banks	3
Battery Capacity (Amp-Hours)	160-800 Ah
Operating Temperature Rating	Reference: T-7
Case Size	16.8" H x 9.6" W x 6.1" D (42.7 cm H x 24.4 cm W x 15.5 cm D) *With Dripshield: +1” Height, +0.5” Depth
Weight	15.2 lbs / 7 kg
Optional Temperature Sensor Model	TCS-12/24
Remote Panel Model	RP
Equalize Option	Yes
Output Indicator Reference	M-3
Compliance	CE

Temperature Ratings

Temperature Range	Performance
-10°C to +60°C	Operates effectively within this temperature range.
Above 50°C	Derates linearly from 100% at 50°C to 80% at 60°C.

Nominal Output Voltages

Configured without temperature compensation, the PT-80 provides the following nominal output voltages based on the selected battery type:

Battery Type	Charge Voltage @ 50% Load (VDC)	Float Voltage @ 0.5 Amp Load (VDC)
Gel-Cell	14.0 VDC	13.6 VDC
Flooded/AGM	14.2 VDC	13.4 VDC

Compliance and Certifications

• USCG CFR 183.410: Ignition protected
• CE: Carries the CE mark
• ABS: PT Series meets SVR 2009 4-8-3/5.9, Under 90 meters Rules 2006 4-6-4/7.19, and HSNC 2007 4-8-3/5.13

Optional Accessories

• Remote Panel (Model RP): Compatible with all models except PT-7 and PT-40U. Features LEDs indicating charger output stage and manual re-initialization of the three-stage charge cycle. Includes 25′ of cable. Panel dimensions: 3″ H x 4.75″ W.
• Temperature Compensation Sensor (Model TCS-12/24): Compatible with all models except PT-7. Offers -5 mV per cell per degree Celsius adjustment. Includes 25′ cable (40′ cable optional).

Additional Specifications

Specification	Details
Charger Input Voltage	115/230 V
Charger Output Amps	80 A
Charger Output Voltage	12 V
Charging Banks	3
Inverter Input Voltage	115/230 V
Inverter Output Voltage	12 V
Outlet Quantity	Hardwire
Portable	No
Box Dimensions	11" H x 15" W x 20" L
Weight	18 lbs

Documentation

• Quick Guide (PDF)
• Owner's Manual (PDF)
