Newmar PT-24-13W Battery Charger

Ensure your marine batteries are always in peak condition with the PT-24-13W Battery Charger. Designed specifically for 24-volt systems on workboats, military and commercial vessels, as well as recreational boats, this smart charger delivers reliable performance, extends battery life, and maximizes efficiency through advanced charging technology.

Smart Charging Technology for Optimal Battery Performance

The PT-24-13W Battery Charger employs intelligent three-stage charging—bulk, absorption, and float—to rapidly recover and condition your batteries. This ensures your marine batteries are always ready for the demands of your vessel, providing consistent power and extending battery longevity.

Versatile Battery Compatibility

Adaptable to various battery types, the charger features a selector switch that adjusts the output voltage for gel-cell, flooded lead-acid, or AGM batteries. Additionally, the optional temperature compensation sensor fine-tunes the output based on ambient temperature changes, ensuring optimal charging conditions under all circumstances.

Rugged and Durable Construction

Built to withstand the harsh marine environment, the PT-24-13W is housed in a sturdy stainless steel case with a durable white powder coat finish. The internal circuitry is coated with polyurethane, offering maximum resistance to corrosion and ensuring long-term reliability even in the toughest conditions.

Comprehensive Features

• 24-volt model tailored for marine applications
• Intelligent three-stage charging: bulk, absorption, float
• Adjustable for Gel-Cell, Flooded Lead-acid, and AGM batteries
• Multiple isolated output banks with ammeter for total current monitoring
• Optional temperature sensor for dynamic voltage adjustment
• Built-in current limiting to prevent overload damage
• Can function as a power supply, powering loads without a battery
• Rugged stainless steel casing with optional drip shield and marinized internal components
• Protection features include Current Limiting, Thermal Protection, Forced Air Cooling, and Drip Shield
• Compatible with PT-MCU for enhanced control and monitoring
• ABS-type approved for safety in battery charging and power supplies

Technical Specifications

Specification	Details
Input Voltage (VAC)	90 – 132, 180 – 264 V (50-60 Hz)
Input Amperage @ Full Load	6.5 A @ 115 VAC, 4 A @ 230 VAC
Power Factor	0.7
Max Output Amperage	13 A
Output Banks	3
Battery Capacity (Amp-Hours)	26 – 130 Ah
Operating Temperature Rating	-10°C to +60°C
Case Dimensions (HxWxD)	11.2" x 7.7" x 4.75" (28.4 cm x 19.6 cm x 12.1 cm)*
Weight	8 lbs / 4 kg
Optional Temperature Sensor Model	TCS-12/24
Remote Panel Model	RP
Compliance	CG, ABS

*With Dripshield installed: Add 1.1” (2.8 cm) to height and 0.92” (2.3 cm) to depth

Temperature Ratings and Performance

• Operating Temperature Range: -10°C to +60°C
• Derating: Performance decreases linearly from 100% at 50°C to 60% at 60°C

Charging Voltage Specifications

Battery Type	Charge Voltage @ 50% Load (VDC)	Float Voltage @ 0.5 Amp Load (VDC)
Gel-Cell	28.0	27.2
Flooded/AGM	28.4	26.8

Safety and Compliance

• UL 1950 certified (per DNB report)
• USCG CFR 183.410 compliant (Ignition protected)
• EN 60335-1 compliant
• CE marked for safety standards
• ABS certified, meeting SVR 2009 4-8-3/5.9, Under 90 meters Rules 2006 4-6-4/7.19, and HSNC 2007 4-8-3/5.13

Available Options and Accessories

• Remote Panel (Model RP): Enhances usability by providing LED indicators for charger output stages and allows manual re-initialization of the three-stage charge cycle. Includes 25’ of cable and measures 3” H x 4.75” W. Compatible with all models except PT-24-20U, PT-24-60, and PT-32-25.

Note: This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns.

Additional Specifications

Feature	Specification
Charger Input Voltage	115/230 V
Charger Output Amperage	13 A
Charger Output Voltage	24 V
Charging Banks	3
Inverter Input Voltage	115/230 V
Inverter Output Voltage	24 V
Outlet Quantity	Hardwire
Portable	No
Box Dimensions	10" H x 10" W x 16" L
Weight	9 lbs

Download the Owner's Manual (PDF)
