Newmar 12-12-6i Power Stabilizer

Ensure your marine electronics operate seamlessly with the 12-12-6i Power Stabilizer. Designed specifically for the demanding marine environment, this robust stabilizing converter delivers consistent, regulated voltage to your sensitive boat systems, safeguarding them from power fluctuations and enhancing overall performance.

Reliable Power for Marine Electronics

The 12-12-6i Power Stabilizer guarantees optimal voltage supply to your boat's electronics, regardless of battery condition. By maintaining a steady output across the entire battery voltage range, it prevents shutdowns, performance drops, and potential damage to sensitive marine circuitry caused by fluctuating input voltage.

Key Features

• Total input/output isolation minimizes conducted line noise
• Compatible with negative ground, positive ground, and floating ground systems
• Can be configured as a battery charger for remote battery maintenance
• Durable anodized aluminum case, ideal for harsh marine environments

Application Benefits

• Operate electronics at optimal input voltage, even from nearly drained batteries
• Boost voltage to compensate for voltage drops in long wire runs from batteries
• Eliminate voltage drops during momentary high current drains, such as engine starts
• Stabilize voltage from various charge sources
• Prevent voltage overshoot when high current loads are removed suddenly

Technical Specifications

Parameter	Specification
Input Voltage	10-16 V
Input Current	8 A
Output Voltage	13.6 V
Output Current (Intermittent)	6 A
Output Current (Continuous)	6 A
Dimensions (H x W x D)	6.5 x 4.0 x 1.75 inches (16.5 x 10.2 x 4.5 cm)
Weight	2 lb. (0.9 kg)
Output	12V or 24V, nominal
Ripple	150 mV P-P maximum
Regulation	1% Line/Load

Duty Cycle Ratings

• Intermittent: Up to 20 minutes on time, 20% duty cycle. Current limit set at approximately 105% of intermittent rating.
• Continuous: 24 hours, 100% duty cycle.
• Idle Current: Less than 100 mA (including power “ON” indicator).
• Operating Temperature: 0-50°C. Derates linearly from 100% at 40°C to 50% at 50°C. Thermal shutdown activates at 70°C case temperature.
• Switching Frequency: 40 kHz.
• Efficiency: Typical 85%.
• Isolation: 250 VDC between Output/Chassis and Input/Chassis.

Mechanical Specifications

• Anodized aluminum heat sink case for enhanced durability
• Front panel terminal block for easy connections
• Heavy-duty mounting flange for secure installation on boats
• Conformal-coated PC board to withstand marine conditions

Customization and Options

• Battery Charger Configuration: Modify the stabilizer to function as a battery charger. (Contact factory)
• Parallel/Redundant Operation: Enable parallel or redundant setups for increased reliability. (Contact factory)
• High-Vibration Mounting Kit: Enhance stability in high-vibration marine environments.
• Non-Standard Output Voltage: Custom output voltages available upon request. (Contact factory)

Extreme Vibration Mounting Kit

Protect your NEWMAR power converters from the rigors of marine travel with the Extreme Vibration Mounting Kit. This specialized kit replaces the standard mounting kit, providing superior shock absorption to ensure reliable performance on high-vibration vessels.

The kit seamlessly integrates into the unit’s mounting flange, acting as a “super shock absorber” for your electronics. Available for all NEWMAR units ranging from 2 to 70 lbs., specify KIT–L for units weighing 2–15 lbs. and Kit–H for units weighing 16-70 lbs.
