Newmar 115-12-35CD Power Supply
Newmar 115-12-35CD Power Supply is backordered and will ship as soon as it is back in stock.
Product Description
Product Description
Ensure the optimal performance and reliability of your marine communication and navigation systems with the 115-12-35CD Power Supply. Designed specifically for the demanding environments of commercial vessels, this robust DC power supply delivers a consistent and noise-free 12-volt output, ensuring your essential equipment operates smoothly under all conditions.
Key Features
- Superior Voltage Regulation: Maintains output voltage within 1% across all rated line and load conditions, ensuring stable power for your navigation and communication devices.
- Rugged Construction: Features a polyurethane conformal-coated PCB and a corrosion-resistant heavy-duty aluminum case with integral shock mounts, guaranteeing durability in harsh marine environments.
- Efficient Thermal Management: Large heat sink fins effectively dissipate heat from semi-conductors, promoting cool and reliable operation even during extended use.
- Comprehensive Protection: Equipped with overvoltage protection, current limiting (set at 105% of intermittent rating), thermal overload protection, and input/output fusing to safeguard both the power supply and connected equipment.
- Active Cooling: Thermally activated cooling fan on “CD” units ensures optimal temperature control and extends the lifespan of the power supply.
Technical Specifications
Parameter | Specification |
---|---|
Nominal Input | 115/230 VAC |
Maximum Input Current @115V | 7.5 A |
Maximum Input Current @230V | 3.5 A |
Output Amperage (Intermittent) | 35 A |
Output Amperage (Continuous) | 35 A |
Weight | 32 lbs / 14.6 kg |
Case Dimensions (H x W x D) | 6.5” x 9.5” x 14.0” |
Input Range
Operates on a selectable input range of 105-125 VAC or 210-250 VAC at 50-60 Hz. Note that the output is derated to 50% below 110 VAC and 220 VAC.
Operating Temperature
C.D. Units: Operates efficiently between 0-65°C. The power supply linearly derates from 100% at 50°C to 50% at 65°C, with thermal shutdown activated at a case temperature of 85°C to prevent overheating.
Duty Cycle
- Intermittent Use: Suitable for applications with a maximum of 20 minutes on time and a 20% duty cycle.
- Continuous Use: Designed for 24-hour, 100% duty cycle operation.
Available Options
- Conversion for use as a battery charger, enhancing versatility for various marine applications.
- Adjustable output voltage, allowing customization within the range of 12.6-14.5 VDC.
- Transfer relay option (ERC) for backup battery support during power failures, ensuring uninterrupted power supply.
Output Voltage
- Standard Output: 13.6 VDC
- Adjustable Range: 12.6-14.5 VDC
- Ripple: 40mV P-P at both 110-125 VAC and 220-250 VAC input
- Voltage Regulation: Maintains within 1% under input variations of 110-125 VAC and 220-250 VAC
Mechanical Features
- Durable powder-coated aluminum heat sink case for enhanced thermal management and corrosion resistance.
- Front panel terminal block for easy and secure wiring connections.
- Heavy-duty mounting flange ensures secure installation on your vessel.
- Conformal-coated PCB protects internal components from moisture and salt exposure.
Please Note: This product cannot be returned to the original point of purchase. For any issues or concerns, please contact the manufacturer directly.
