Lopolight Masthead/360-Degree Light - 3NM - Silver Housing w/FB Base

The Masthead/360-Degree Light - 3NM - Silver Housing with FB Base is a high-performance navigation light designed for marine applications. Featuring a sleek silver anodized aluminum housing and a 360-degree visibility range, this horizontally mounted light ensures optimal safety and reliability for vessels under 20 meters.

Key Features

• Durable silver anodized aluminum housing
• 360-degree visibility with a 3 nautical mile range
• FB base for centered wiring and sleek mounting
• Includes a pre-cabled 0.75m marine-grade shielded cable
• IP68 waterproof rating for maximum protection
• Complies with COLREG72, EN14744, IEC 60945, IACS E10, USCG, ABS, M.E.D., DNV, and LR standards

Specifications

Attribute	Details
Housing Material	Silver anodized aluminum 25µ
Lens Material	PMMA
Screws	A4 stainless steel
Sealing	Epoxy, Polyurethane
IP Rating	IP68
Visible Range	3NM
Voltage Input Range	10-32VDC
Current Consumption @ 24VDC	148 mA
Current Consumption @ 12VDC	300 mA
Power Draw	3.6 W
Dimensions (Metric)	Ø92.5mm x 36mm
Dimensions (Imperial)	Ø3.6" x 1.4"
Operating Temperature	-25°C to 55°C
Mounting Type	Horizontal
Feed Wire Gauge	Min. 0.5mm² AWG22
Voltage	10 - 32VDC
Box Dimensions	3"H x 3"W x 3"L
Weight	1.15 lbs
UPC	879343043667
EAN	5704438043534
Vessel Size	Under 12-20 meters

Installation

The Masthead/360-Degree Light features an FB base that simplifies installation by centering the wiring for antenna-type pole mountings. The base offers both screw-down onto the deck and from-below mounting options, providing a sleek and low-profile solution suitable for various marine setups. Follow the included installation guide for detailed instructions to ensure secure and optimal placement.

Package Includes

• 1 Navigation Light
• Pre-cabled with 0.75 meter shielded marine-grade cable
• Installation Guide

For additional guidance, download the Quick Guide (PDF).
