Lewmar Windlass Thermal Circuit Breaker Panel - 70Amp

The Windlass Thermal Circuit Breaker Panel - 70Amp is a robust, panel-mounted solution tailored for marine and boating applications. Designed to endure harsh marine environments, this waterproof breaker provides reliable protection for your DC systems up to 48 volts, ensuring the safe and efficient operation of your windlass circuits.

Features

• Compatible with DC systems up to 48 volts
• Clear, single lever operation for easy handling
• Integrates switching and circuit protection into a single device
• Trip-Free design prevents the breaker from being held "ON" during fault conditions
• Ignition protected for enhanced safety

Technical Specifications

Parameter	Details
Circuit Breaker Class	Type III
Circuit Breaker Type	Thermally responsive bi-metal blade
Maximum Voltage	48V DC
Amperage	70Amp
Mounting	Panel Mount
Weight	0.5 lb (0.23 kg)

*Sold as an Individual Unit

Additional Specifications

Parameter	Details
Amperage	100A
Box Dimensions	1" H x 4" W x 5" L
Weight	0.4 lbs
