Lenco 102XD Extreme Duty Actuator - 24V - 4-1/4" Stroke - 5/16" Hardware

The 102 XD Actuator is a high-performance electric actuator designed specifically for marine and boating applications. Compatible with Trolling Tab systems sold after 2000 and various OEM applications, this actuator ensures reliable and instant response to enhance your boating experience.

Product Overview

The 102 XD Actuator features a robust 4.25-inch stroke and an overall length of 13.25 inches from tip to tip. Constructed from high-impact, glass fiber-filled, ultraviolet-resistant nylon, it is built to withstand the harsh marine environment. The actuator is reinforced with 316 super buff stainless steel tubing, ensuring durability and longevity even in corrosive saltwater conditions.

Key Specifications

Voltage	24 Volt
Stroke Length	4-1/2 inches
Overall Length	13.25 inches
Mounting Hardware	5/16" mounting hardware included
Cable Length	6 feet

Advanced Features

• Anti Extrusion Ring (AXR) Seal Stabilization: Newly implemented to enhance seal durability and prevent extrusion.
• Enhanced Top Cap and Mounting Clevis: Provides a stronger and more secure mounting design.
• Pressure-Tight Torx Screws: Improved screws ensure a reliable, pressure-resistant connection.
• Integrated Wiper Seal: Located at the actuator base to keep contaminants out.
• Brass Thrust Bearing: Molded-in design for increased strength and longevity.
• Reinforced Motor Housing: Thicker walls provide better protection and durability.
• Enhanced O-Ring Design: More consistent sealing performance.
• Over-Molded Cable: Ensures a stronger and tighter seal against water intrusion.
• Upper Mounting Bracket with Gland Seal: Provides an additional layer of protection against moisture.

Performance Benefits

• Reliable and Powerful: Lenco's ballscrew design offers twice the power and reliability compared to typical hydraulic systems.
• High-Torque Actuator Motor: Capable of pushing up to 500 pounds with ease.
• Waterproof Connections: Utilizes waterproof "Plug & Play" Deutsch connectors to prevent water intrusion.
• Efficient Power Supply: Operates on a 24 Volt system, suitable for marine electrical setups.

Additional Resources

Download the Quick Guide (PDF)
