Jabsco Par-Max HD4 Heavy Duty Water Pressure Pump - 24V - 4 GPM - 60 PSI

The Par-Max HD4 Heavy Duty Water Pressure Pump is engineered specifically for marine and boating applications, delivering reliable and powerful water flow to meet the demanding needs of vessel systems. With its robust 24V motor, high flow rate of 4 GPM, and maximum pressure of 60 PSI, the HD4 ensures optimal performance and longevity, making it an essential component for any serious boating enthusiast.

Overview

The HD4 model stands out with its heavy-duty construction, including a wider diameter motor, powder-coated shell, and cast aluminum endbells. These features enhance pressure capability and extend the pump's lifespan, even in harsh marine environments. Available in configurations up to 6 GPM (23 LPM) and 60 PSI (4.1 BAR), the HD4 is designed to deliver exceptional performance for various marine water systems.

Key Features

• Co-Molded Diaphragm Technology: Ensures long life and durability, reducing the need for frequent replacements.
• Heavy Duty Construction: Features robust motors and cast aluminum lower housings for enhanced longevity, even under high pressure.
• Quiet and Efficient Operation: Minimizes noise, providing a more comfortable onboard experience.
• Integrated Sealed Pressure Switch: Facilitates on-demand operation, optimizing performance based on water usage.
• Self-Priming Capability: Allows for versatile installation options, accommodating various marine setup configurations.
• Dry Run Protection: Can run dry without sustaining damage, safeguarding the pump during low water conditions.
• Quick Connect Ports: Simplifies installation, servicing, and maintenance, saving time and effort.
• Vibration Dampening Mounting Feet: Reduces operational vibrations, enhancing overall pump stability and longevity.
• Integrated Bypass Module: Minimizes cycling and provides a smoother water flow, ensuring consistent performance.

Technical Specifications

Safety Information

WARNING: This product can expose you to chemicals including ANTIMONY OXIDE (ANTIMONY TRIOXIDE) which is known to the State of California to cause cancer. For more information, visit P65Warnings.ca.gov.

Additional Resources

For more detailed information, refer to the Brochure (PDF).
