Jabsco Par-Max 1 Water Pressure Pump - 12V - 1 GPM - 35 PSI
Jabsco Par-Max 1 Water Pressure Pump - 12V - 1 GPM - 35 PSI is backordered and will ship as soon as it is back in stock.
Product Description
Product Description
The Par-Max 1 Water Pressure Pump is an essential component for marine and boating applications, delivering reliable water pressure at 1 gallon per minute (GPM) and 35 PSI. Designed for efficiency and durability, this 12V pump ensures your vessel's water systems operate smoothly and effectively.
Exceptional Performance for Marine Applications
Engineered with both standard and heavy-duty configurations, the Par-Max water pressure pump caters to various boating needs. The Heavy Duty (HD) models feature a wider diameter motor, powder-coated shell, cast aluminum endbells, and lower housing to enhance pressure capability and longevity. These models are available up to 6 GPM and 60 PSI, making them ideal for larger vessels with multiple water outlets.
Standard models provide an economical solution without compromising performance, offering 1 to 3 GPM suitable for boats with 1-3 water outlets. The plastic housing effectively protects the motor from corrosion, ensuring consistent operation even in harsh marine environments.
Key Features
- Co-molded diaphragm technology for enhanced durability and long life
- Heavy Duty (HD) models with robust motors and cast aluminum lower housings for sustained high-pressure performance
- Efficient and quiet operation, minimizing noise on board
- Integrated, sealed pressure switch for on-demand activation
- Self-priming capability offering versatile installation options
- Ability to run dry without sustaining damage
- Quick connect ports facilitating easy installation, service, and maintenance
- Vibration dampening mounting feet reducing operational vibrations
- Integrated bypass module reducing cycling and providing smoother water flow
Specifications
| Attribute | Details |
|---|---|
| Motor Design | Brushed, permanent magnet TENV |
| Pumphead Upper Housing Material | Glass fiber reinforced polypropylene |
| Diaphragm | Co-molded TPV |
| Check Valves | EPDM |
| Max Inlet Pressure | 30 PSI (2.1 Bar) |
| Fluid Temperature Range | 32°F – 140°F (0°C – 60°C) |
| Dry Self-Priming Capability | 7ft min (2.13m/min) |
| Certifications | CE, ISO8846, RCM |
| Ingress Protection | IPX6 |
| Voltage | 12V |
| Max PSI | 35 PSI |
| Gallons Per Minute | 1 GPM |
| Box Dimensions | 2"H x 6"W x 6"L |
| Weight | 2.2 lbs |
| UPC | 671880841757 |
Safety Information
WARNING: This product can expose you to chemicals including ANTIMONY OXIDE (ANTIMONY TRIOXIDE) which is known to the State of California to cause cancer. For more information, visit P65Warnings.ca.gov.
