HEISE Infinite Series 22" RGB Backlite Dualrow Bar - 24 LED
HEISE Infinite Series 22" RGB Backlite Dualrow Bar - 24 LED is backordered and will ship as soon as it is back in stock.
Product Description
Product Description
The Infinite Series 22" RGB Backlite Dualrow Bar is the ultimate lighting solution for marine and boating enthusiasts. Engineered to deliver stunning illumination with 16 million selectable colors and pure white light, this durable and versatile light bar enhances visibility and aesthetics on any vessel. Controlled seamlessly via a mobile app, it is designed to withstand the harshest marine environments, ensuring reliable performance on every journey.
Product Features
- Vibrant RGB and Pure White Lighting: Choose from 16 million colors or a steady pure white light to match your boat's style and your personal preference.
- Mobile App Control: Easily manage your lighting settings and synchronize multiple Infinite Series bars using a user-friendly mobile application.
- Robust Construction: Crafted with a virtually unbreakable polycarbonate lens and a die-cast aluminum housing to endure the toughest marine conditions.
- Moisture Resistant: Features a military-grade breather port that allows moisture to escape, preventing condensation and prolonging the life of the light bar.
- Expandable System: Compatible with Heise's popular RGB accent lights through the HE-CBRGB controller (sold separately), enabling comprehensive lighting setups for larger vessels.
Specifications
Feature | Details |
---|---|
Input Voltage | 10-30V DC |
Wattage | 60W |
Raw Lumens | 7,600 |
LUX @ 10M | 1,150 |
Color Temperature | 6000K |
Beam Pattern | Spot (8°) |
Length | 22" |
Voltage - Input Range | 12/24V |
Box Dimensions | 6"H x 6"W x 26"L |
Weight | 7.6 lbs |
UPC | 086429368433 |
Construction
Component | Specification |
---|---|
Housing Material | Die-cast Aluminum |
Housing Color | Black |
Lens Material | Polycarbonate (PC) |
Mounting Bracket | Die-cast Aluminum |
Hole Dimensions | Brackets turned inward - 21.25" Brackets turned outward - 23.5" |
Mounting Bolt Drill | .25" |
Height of Light Bar | 4.8" |
Depth of Light Bar | 3.50" |
Electronics | Integrated-Epoxy Encapsulated |
Hardware | Stainless Steel 316 |
Operation
Parameter | Specification |
---|---|
Operating Temperature | -40°C to +60°C |
Current Consumption | 4.34 amps @ 13.8 volts |
IP Rating | IP67 |
Protections | Reverse Polarity Protection |
Installation
Installing the Infinite Series 22" RGB Backlite Dualrow Bar on your boat is straightforward. The die-cast aluminum mounting brackets are designed for secure attachment, either turned inward at 21.25" or outward at 23.5", depending on your mounting preferences. Ensure proper spacing and alignment for optimal lighting performance. The robust stainless steel 316 hardware provides enduring strength against marine elements.
Compatibility
The Infinite Series RGB bar utilizes the HE-CBRGB controller, which is sold separately. This controller not only manages the Infinite Series but also allows synchronization with Heise’s other RGB accent lights, providing a unified and customizable lighting experience across your vessel. Expand your lighting system effortlessly to achieve cohesive illumination tailored to your boating needs.
Safety Warning
WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects, or other reproductive harm. For more information, visit P65Warnings.ca.gov.
