Garmin Airmar CM599LHW 1-3kW Pocket Mounted Transducer, 28-60 150-250kHz

Enhance your marine navigation with the Airmar CM599LHW Pocket Mounted Transducer, a robust and compact solution designed for seamless integration with your Garmin Marine Network. Offering precise depth and temperature readings, this transducer is built to withstand the demands of the marine environment while providing reliable performance for your boating adventures.

Key Features

• Compact Design: Pocket mounted for easy installation without compromising performance.
• Power Range: Operates between 1-3 kW to cater to various marine applications.
• Depth Capability: Capable of measuring depths up to 10,000 feet, ideal for deep-sea exploration.
• Dual Frequency Operation: Supports low frequencies (28-60 kHz) with very narrow beams and high frequencies (150-250 kHz) with wide beams.
• Beamwidth Options: Choose between 9x23 degrees or a constant 25 degrees to suit your specific needs.
• Durable Construction: Bare wire design encased in robust plastic housing for longevity and reliability.
• Flexible Mounting: Pocket mount installation adaptable to various boat types and configurations.

Specifications

Feature	Details
Temperature Measurement	Yes
Speed Included	No
Pins	Bare Wires
Mounting Style	Pocket
Cable Length	70 feet
Chirp	Low/High Wide
Imaging	Standard
Box Dimensions	12"H x 13"W x 17"L
Weight	33.5 lbs
UPC	753759123628

Easy Installation

The Airmar CM599LHW comes with comprehensive installation instructions to ensure a hassle-free setup. Installation is dependent on your specific boat configuration, so it is recommended to follow the provided guidelines meticulously to prevent any potential damage to your vessel or the transducer.

Safety Information

WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects, or other reproductive harm. For more information, visit P65Warnings.ca.gov.

Additional Resources

• Owner's Manual (PDF)
• Brochure (PDF)
