Furuno 525STID-PWD Plastic 600W Transom Mount 10 Pin Transducer

The 600W Transom Mount Transducer is engineered for marine enthusiasts seeking reliable and high-performance sonar capabilities. Whether you're fishing, navigating, or exploring underwater environments, this transducer delivers precise and clear data to enhance your boating experience.

Key Features

• Powerful Performance: Equipped with a 600-watt motor, ensuring robust and consistent sonar signals.
• Dual Frequency Operation: Supports both 50 kHz and 200 kHz frequencies for versatile underwater imaging.
• Optimized Beam Angles: Features 45 and 11-degree beam angles for comprehensive coverage and detailed target separation.
• Durable Construction: Constructed with a high-quality plastic transom mount, designed to withstand harsh marine environments.
• Temperature and Speed Assembly: Includes a temperature sensor and a removable speed assembly for easy maintenance and accurate speed readings.
• Extended Connectivity: Comes with a 30-foot cable featuring a 10-pin connector, providing flexibility in installation.

Technical Specifications

Specification	Details
Power	600 Watts
Frequency	50/200 kHz
Beam Angles	45/11 degrees
Mounting Style	Transom
Cable Length	30 feet
Connector	10-Pin
Temperature Sensor	Included
Speed Assembly	Removable
Box Dimensions	4"H x 8"W x 10"L
Weight	2.6 lbs
UPC	6116793104468

Compliance and Returns

WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information, visit P65Warnings.ca.gov.

Note: This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns.

Additional Resources

• Quick Guide (PDF)
• Brochure (PDF)
