Furuno 12V-24V 7 Amp Converter f/DRS12AX X-Class Open Array - Newmar

Enhance your marine vessel's electrical system with the Newmar 12V-24V 7 Amp Converter, specifically designed for the DRS12AX X-Class Open Array. This reliable DC-DC converter efficiently steps up 12 volts to 24 volts, enabling seamless integration of dual voltage applications without the need for additional 24-volt batteries or dedicated charging systems. Ideal for boaters seeking robust and versatile power management solutions, this converter ensures your onboard electronics operate smoothly and efficiently.

Key Features

• Dual Voltage Capability: Converts 12V systems to 24V, perfect for managing multiple electrical applications on your vessel.
• Reliable Performance: Continuous 7 Amp output with high efficiency ensures consistent power supply.
• Compact and Durable Design: Constructed with anodized aluminum and glass-filled polycarbonate, offering dust, water, and impact resistance up to IP53.
• Easy Installation: Front panel terminal block simplifies wiring, while the green LED output indicator provides quick status checks.
• Advanced Protection: Features current limiting, voltage spike suppression, automatic thermal shutdown, and recovery to safeguard your electronics.

Technical Specifications

Parameter	Details
Input Voltage	10 - 15 VDC
Output Voltage	27.2 VDC ±5%
Ripple	<100 mV P-P
Regulation	±5% Line/Load
Duty Cycle	Intermittent: 2 minutes, 20% duty Continuous: 24 hours, 100% duty
Operating Temperature	-25°C to 30°C (derated linearly from 30°C to 0% at 80°C)
Efficiency	93% Typical

Installation Types

Choose the appropriate converter type based on your marine application's requirements:

Standard, Non-Isolated Series

• Designed for negative ground systems
• Shared common negative ground between 12V input and 24V output
• Ideal for electronics that perform better on 24V with a robust 12V system
• Available in 7, 16, and 25 Amp output models

Mechanical Specifications

• Construction: Anodized aluminum and glass-filled polycarbonate for durability
• Protection Rating: IP53 for dust, water, and impact resistance
• Terminal Block: Front panel for easy access and wiring
• Indicator: Green LED output indicator for status monitoring
