Blue Sea 8084 AC Main +6 Positions/DC Main +15 Positions Toggle Circuit Breaker Panel - White Switches

The 8084 AC Main +6 Positions/DC Main +15 Positions Toggle Circuit Breaker Panel is a high-quality electrical management solution designed specifically for marine and boating applications. Its robust construction and comprehensive feature set ensure reliable performance and safety for your vessel's electrical systems.

Features

• Includes a set of 30 common AC and 30 common DC labels for easy identification
• All AC and DC buses are pre-installed and fully pre-wired for quick setup
• Label backlighting is pre-installed for enhanced visibility in low-light conditions
• All indicator LEDs are pre-installed to provide real-time status updates
• Maximum panel amperage: 100 Amperes DC / 50 Amperes AC, suitable for high-demand marine applications

AC Features

• Reverse Polarity Indicating LED: Red LED alerts you to any reverse polarity issues, ensuring the safety of your AC systems
• Optional 4029 AC Isolation Cover: Ready for installation to provide additional protection and meet specific marine standards
• 9353, 0-150 Volt AC Voltmeter: Monitor your AC voltage levels accurately

DC Features

• 100 Amp C-Series Circuit Breaker: Provides robust main circuit protection and switching for your DC branch circuits
• 8003, 8-16 Volt DC Voltmeter: Keeps track of your DC voltage
• 8017, 0-100 Amp DC Ammeter: Measures the current flowing through your DC circuits
• Upgradeable to 24 Volts: Owner-upgradeable with the 8240, 18-32 Volt DC Voltmeter for enhanced flexibility

Specifications

Attribute	Details
AC Positions	Main +6
DC Positions	Main +15
Voltage	120V AC / 12V DC
Breaker Configuration	(1) 30A - (3) 15A AC Circuit Breakers (1) 100A - (9) 15A DC Circuit Breakers
Box Dimensions	7"H x 15"W x 23"L
Weight	8.6 lbs
UPC	632085080846

*Combined AC/DC panels require an AC Insulating Cover to meet ABYC Standards.

Safety Warning

WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (DEHP), which is known to the State of California to cause cancer, birth defects, or other reproductive harm. For more information, visit P65Warnings.ca.gov.

Owner's Manual

Download the Owner's Manual (PDF)
