Blue Sea 7036 187 - Series Thermal Circuit Breaker - 30Amp

The 187-Series Thermal Circuit Breaker is an essential component for marine and boating electrical systems, providing reliable protection and seamless switching for your vessel's power needs. Designed for panel mount installation, this 30 Amp breaker ensures safe and efficient operation in harsh marine environments.

Key Features

• Integrates switching and circuit protection in a single, compact device, simplifying your electrical setup.
• Constructed with components that meet SAE J1171 external ignition protection standards, ensuring safety in gasoline-powered boats.
• Easy-to-use single lever operation for clear and intuitive control.
• "Trip Free" mechanism prevents the breaker from being held in the "ON" position during fault conditions, enhancing safety.
• Waterproof design guards against moisture and corrosion, ideal for marine environments.
• Recessed mounting holes provide a clean and streamlined panel appearance.
• Self-trimming case eliminates the need for additional mounting panels or trim bezels, simplifying installation.
• Round case shape allows for easy installation with standard hole saw sizes.
• Spacious clearance around terminal studs accommodates heavy gauge wire lugs for robust connections.
• Durable 5/16" terminals deliver high torque connections, ensuring secure electrical contact.
• Large lever with selectable vertical or horizontal orientation offers clear indication of the trip status.
• Ignition protected, making it safe for installation aboard gasoline-powered boats.

Specifications

General
Amperage:	30 Amp
Circuit Breaker Class:	Type III - Switchable / Manual Reset - Trip Free
Type:	Thermally Responsive Bi-Metal Blade
Case Material:	Thermoset Polyester
Voltage Rating:	48 Volts DC Maximum
Interrupt Rating:	5,000 Amperes @ 12 Volts DC 3,000 Amperes @ 24 Volts DC 1,500 Amperes @ 42 Volts DC
Operating Temperature Range:	-25°C to +82°C

Product Details

• Box Dimensions: 2"H x 5"W x 8"L
• Weight: 0.45 lbs
• UPC: 632085070366
