Blue Sea 4306 WeatherDeck Water Resistant Fuse Panel - 6 Position - Grey

The WeatherDeck™ Water Resistant Fuse Panel is an essential component for marine electrical systems, offering robust protection and reliable performance even in harsh marine environments. Designed specifically for flybridge and open cockpit applications, this fuse panel ensures your boat’s electrical circuits are safe and easily manageable.

Key Features

• Waterproof Design: Rated IP67 when properly mounted with a watertight mounting gasket, providing protection against immersion up to 1 meter for 30 minutes.
• Versatile Installation: Each panel can be mounted in four different orientations, allowing flexibility in various boat layouts.
• Independent Backlighting: Features an independent label backlighting circuit for remote switching and dimming, enhancing visibility in low-light conditions.
• Enhanced Circuit Identification: Bicolored LEDs illuminate circuit labels to indicate OFF (Red), ON (Green), or Blown (No Color) states. Absence of lights may indicate no power to the panel.
• Integrated Protection: Equipped with ATO/ATC fuse-based circuit protection to safeguard your electrical system.

Technical Specifications

Specification	Details
Waterproof	IP67 Rated
Voltage	12V DC
AC/DC	DC
Positions	6
Maximum Amperage	15A @ 12V DC (per circuit)
Panel Cumulative Rating	90A
Backlit Label	Bicolored LED
Backlighting Amperage	10mA per illuminated circuit
Backlighting Voltage	12V DC
Dimensions	Height: 6.0"    Width: 3.88"    Depth: 2.5"
Box Dimensions	5"H x 6"W x 9"L
Weight	1.5 lbs
UPC	632085043063

What's Included

• (6) WeatherDeck® Toggle Switch Boots - Black (Model 4138)
• (6) WeatherDeck® Toggle Switch SPST - ON-OFF (Model 4150)
• (1) Waterproof DC Label Kit - 30 Black Square Labels V1 (Model 4215)
• (6) ATO/ATC Fuses - 15 Amp (Model 5242)

Safety Information

WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (DEHP), which is known to the State of California to cause cancer, birth defects, or other reproductive harm. For more information, visit P65Warnings.ca.gov.

Additional Resources

Download the Quick Guide (PDF)
