Blue Sea 4304 WeatherDeck Water Resistant Fuse Panel - 4 Position - Grey

The WeatherDeck™ Water Resistant Fuse Panel is the ultimate solution for managing your boat's electrical systems with reliability and ease. Engineered specifically for marine environments, this fuse panel ensures your circuits are protected and easily accessible, whether you're navigating the open seas or enjoying a day on the flybridge.

Product Details

• Model Number: 4304
• Color: Gray

Features

• Superior Waterproofing: Rated IP67, the panel is protected against immersion up to 1 meter for 30 minutes when properly mounted with a watertight gasket.
• Marine-Grade Design: Specifically crafted for flybridge and open cockpit applications, ensuring durability in harsh marine conditions.
• Flexible Installation: Each panel can be mounted in four different orientations for optimal placement and accessibility.
• Advanced Circuit Protection: Integrated ATO/ATC fuse-based circuit protection safeguards your electrical systems from overloads.
• Intuitive Label Backlighting: Bicolored LEDs (Red for OFF, Green for ON, and no color for Blown circuits) illuminate labels for quick circuit identification. Absence of lights may indicate no power to the panel.
• Independent Lighting Control: Backlighting circuit can be remotely switched and dimmed for convenience.

Specifications

Feature	Details
Waterproof Rating	IP67
Power Type	12V DC
Number of Positions	4
Maximum Amperage per Circuit	15A @ 12V DC
Cumulative Panel Rating	60A
Backlighting	Bicolored LEDs
Backlighting Amperage	10mA per Illuminated Circuit
Backlighting Voltage	12V DC
Dimensions	4.3" (H) x 3.88" (W) x 2.5" (D)
Weight	0.9 lbs
UPC	632085043049

What's Included

• (4) 4138 WeatherDeck® Toggle Switch Boots - Black
• (4) 4150 WeatherDeck® Toggle Switch SPST - ON-OFF
• (1) 4215 Waterproof DC Label Kit - 30 Black Square Labels V1
• (4) 5242 ATO/ATC Fuses - 15 Amp

Safety Information

WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (DEHP), which is known to the State of California to cause cancer, birth defects, or other reproductive harm. For more information, visit P65Warnings.ca.gov.

Additional Resources

Download the Quick Guide (PDF)
