Blue Sea 4302 WeatherDeck Water Resistant Fuse Panel - 2 Position - Grey

The WeatherDeck™ Water Resistant Fuse Panel is engineered for marine and boating applications, providing reliable and secure electrical management in demanding environments. Its robust design ensures protection against harsh weather conditions, making it an ideal choice for flybridge and open cockpit setups.

Product Features

• IP67-rated front panel for superior water resistance when mounted with the included watertight gasket
• Protected against immersion up to 1 meter for 30 minutes, ensuring durability in wet conditions
• Specifically designed for flybridge and open cockpit applications, meeting the unique needs of marine environments
• Independent label backlighting circuit allows for remote switching and dimming, enhancing usability in low-light conditions
• Flexible installation with four mounting orientations available for each panel
• Integrated ATO/ATC fuse-based circuit protection for added safety
• Bicolored LEDs provide clear visual indicators for circuit status: OFF (Red), ON (Green), or Blown (No Color). Absence of lights may indicate no power to the panel.

Specifications

Attribute	Details
Weatherproof	Waterproof
Protection Rating	IP67 – Immersion up to 1m for 30 minutes
Voltage	12V DC
Circuit Protection	Fuse
Maximum Amperage	15A @ 12V DC per circuit
Panel Cumulative Rating	30A
Backlit Label	Bicolored LED
Backlighting Amperage	10mA per illuminated circuit
Backlighting Voltage	12V DC
Dimensions	Height: 2.6", Width: 3.88", Depth: 2.5"
Box Dimensions	5"H x 6"W x 6"L
Weight	0.5 lbs
UPC	632085043025

What's Included

• (2) 4150 WeatherDeck® Toggle Switch SPST - ON-OFF
• (1) 4215 Waterproof DC Label Kit - 30 Black Square Labels V1
• (2) 5242 ATO/ATC Fuse - 15 Amp

Safety Information

WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (DEHP) which is known to the State of California to cause cancer, birth defects, or other reproductive harm. For more information, visit P65Warnings.ca.gov.

Additional Resources

Quick Guide (PDF)
