Analytic Systems Waterproof IP66 DC Converter 10A, 24V Out, 30-80V In, Ruggedized

Ensure reliable power conversion on your boat with the Waterproof IP66 DC Converter 10A. Designed specifically for marine environments, this ruggedized converter delivers consistent 24V output from a wide input range of 30-80V DC, ensuring your onboard electronics run smoothly even in challenging conditions.

Product Overview

The VCH10 Step Down Voltage Converter is engineered to meet the demanding needs of marine and boating applications. With an IP66 watertight rating and EMC shielding, it withstands harsh marine environments while providing stable power for your vessel's electrical systems. Whether you're powering navigation equipment, lighting, or other critical devices, the VCH10 ensures optimal performance with up to 10 amps of output current.

Key Features

• Watertight O-ring sealed and EMC gasketed enclosure
• Military-grade MIL connectors for secure input and output
• LED indicators for 'Output ON' and 'Overload' status
• Compact design for easy mounting in tight spaces
• Wide input range up to 80V DC
• Heavy-duty ruggedization with operation from -40°C to +55°C
• Paralleling diodes for enhanced performance
• Custom output voltages available to suit specific needs
• Two-year warranty covering parts and labor

Technical Specifications

Parameter	Specification
Input Voltage	30-80 VDC
Output Current	10A
Output Voltage	24V DC
Power Capacity	Up to 544 Watts at 48 VDC Out
Dimensions	5" H x 8" W x 10" L
Weight	2.05 lbs

Durability and Protection

Built to endure the rigors of marine environments, the VCH10MW model is rated IP66 for complete protection against dust and powerful water jets. It operates reliably in extreme temperatures ranging from -40°C to +55°C, making it suitable for various boating conditions. Additionally, it complies with MIL-STD-461F for radiated and conducted emissions and MIL-STD-810G for shock and vibration, ensuring dependable performance on the water.

Protection Features

• Reverse input protection to prevent damage from incorrect connections
• Output current limiting to safeguard your devices
• Over-voltage protection to maintain safe operating conditions

Installation and Connectivity

The standard VCH10W model comes with a Deutsch connector on a pigtail input/output cable for straightforward connections. For enhanced security and durability, the military-grade VCH10MW features separate bayonet-style MIL connectors for both input and output. Its compact size allows for easy mounting in various locations on your boat, ensuring a seamless integration with your existing electrical system.

Warranty

We stand behind the quality of our VCH10 DC Converter with a comprehensive two-year warranty covering both parts and labor, giving you peace of mind with your purchase.
