Airmar CM599LH 1-3kW Pocket Mounted Transducer - No Connector

The CM599LH Dual-Band Pocket Mounted Transducer is a top-tier, connector-free solution designed for marine enthusiasts seeking unparalleled sonar performance in deep-water settings. Perfect for targeting elusive species like swordfish and tuna, this transducer delivers crystal-clear imaging and extensive coverage, making it an essential addition to any serious angler's arsenal.

Unmatched Sonar Performance

Engineered with advanced Chirp-ready technology, the CM599LH seamlessly integrates low-frequency capabilities down to 3,000 meters (10,000 feet) with high-frequency precision. This dual-band functionality ensures both deep penetration and high-resolution imaging, providing anglers with a comprehensive view of their underwater environment.

Advanced Technical Specifications

Specification	Details
Frequency Band	Dual-Band Low (28-60 kHz) and High (130-210 kHz)
Power Rating	2-3 kW
Maximum Operating Depth	Low Frequency: Up to 3,048 meters (10,000 feet) High Frequency: Up to 457 meters (1,500 feet)
Beamwidth	Low Frequency: 11°x23° to 5°x9° High Frequency: 8°-4°
Total Bandwidth	112 kHz from a single transducer
Cable Length	15 meters (49 feet)
Product Weight	14.2 kg (31.2 lbs)
Material Composition	High-strength Urethane
Manufactured In	USA

Key Features

• Dual-Band Capability: Combines low and high-frequency transducers for versatile sonar functionality.
• Chirp-Ready Technology: Enhances depth penetration and high-resolution imaging.
• Powerful Output: 2 to 3 kW ensures robust performance in deep-water applications.
• Narrow Beamwidth: 8° to 4° at high frequencies for precise target detection.
• Wide Detection Range: Low Frequency Range of 28 to 60 kHz for comprehensive underwater coverage.
• Durable Construction: Resin housing with a curved-edge design for seamless wet-box installation.
• Flexible Installation: Compatible with cavity-mounted or welded tank setups, available in thru-hull (R509LH) and in-hull (R599LH) mounts.
• Innovative Xducer ID® Technology: Ensures reliable transducer identification.
• Temperature and Depth Sensing: Advanced sensors provide accurate water temperature and depth measurements.
• Supports Popular Fishing Frequencies: Compatible with 50 and 200 kHz, along with the full bandwidth range.

Technical Specifications

• Primary Functions: Depth Measurement, Temperature Sensing
• Mounting Styles: Tank, Cavity, and Pocket/Keel Mount installations
• Connection Type: Bare Wire for flexible integration
• Display Connector: Not included
• Hull Material Compatibility: Suitable for Fiberglass or Metal Hulls
• Maximum Vessel Length Overall (LOA): 8 meters (25 feet) and above
• Common Applications: Professional Fishing, Commercial Fishing Operations
• Maximum Deadrise Angle: Universally compatible with any deadrise angle through custom installation
• Tilted Element: Not applicable
• Frequency Capability: CHIRP-Ready Dual-Band for enhanced sonar functionality

Installation and Compatibility

The CM599LH Transducer offers versatile installation options to suit various vessel configurations. Whether you prefer cavity-mounted or welded tank setups, this transducer adapts seamlessly. Available in thru-hull external (R509LH) and in-hull (R599LH) mounts, it is compatible with both fiberglass and metal hulls, ensuring a perfect fit for boats with a length overall (LOA) of 8 meters (25 feet) and above.

Durability and Design

Constructed from high-strength urethane, the CM599LH is built to withstand the harsh conditions of deep-sea environments. Its resin housing with a curved-edge design allows for easy and seamless wet-box installation, providing both durability and aesthetic appeal.

Additional Information

Note: This product cannot be returned to the original point of purchase. For any issues or concerns, please contact the manufacturer directly.

Download Quick Guide (PDF)
Download Brochure (PDF)
