Paneltronics Breaker 5 Amps A-Frame Magnetic Waterproof

Ensure the safety and reliability of your marine electrical systems with our Panel Seal/Waterproof "A" Frame Magnetic Circuit Breakers. Specifically designed for marine and boating applications, these circuit breakers offer robust protection against electrical overloads and short circuits, ensuring your vessel's electrical distribution remains secure and efficient.

Features

• Compatible with both AC and DC systems, ideal for Paneltronics electrical distribution panels.
• Durable metal handle complemented by a silicon rubber seal for enhanced longevity and waterproofing.
• Rated for a maximum of 50 Amps, accommodating a wide range of marine electrical needs.
• Capable of handling up to 32 VDC and an Interrupting Capacity (AIC) of 2,500 amps without a back-up fuse.
• Designed for high durability with 10,000 rated switch cycles at specified current and voltage.
• Trip-free mechanism ensuring uninterrupted protection as per ABYC standards.
• Manual reset feature for secure and controlled circuit management.

Compliance & Certification

• Meets all American Boat and Yacht Council (ABYC) Standards for non-ignition protected circuit breakers.
• UL Recognized (UL 1077) for safe use in the USA.
• CSA Certified, ensuring compliance and safety standards for use in Canada.
• Complies with ABYC standards E-11.10.1.5.4 and E-11.10.2.1.1 for trip-free operation.
• Adheres to ABYC standards E-11.10.1.5.6 and E-11.10.2.1.1 for manual reset functionality.

Technical Specifications

Color	Stainless
Throw/Pole	SPST
Box Dimensions	2" H x 2" W x 2" L
Weight	0.2 lbs
UPC	602290201404

Included Hardware

• Hex nut 1/2-32
• Lockwasher with 1/2" internal tooth

Optional Accessories

• Black silicone rubber boot (P/N 048-015)
